Product characteristics
◆ The control system adopts intelligent micro-computer control, touch the key to adjust the settings, LCD screen can display the working
area temperature, fan operation, lighting, sterilization lamp and other operation status.
◆ Temperature sensor: it can detect and display the temperature in real time.
◆ Equipped with filter failure, damage and blocking alarm technology, equipped with fan overload alarm prompt to remind the user to
replace the filter in time.
◆ The worktop is made of integrated high quality stainless steel, corrosion-resistant and easy to clean.
◆ The front 10 ° inclined operation surface is more ergonomic and comfortable to operate.
◆ Safety interlock protection design, UV lamp and lighting lamp interlock, when the lighting lamp, UV lamp can be turned on, to prevent
the wrong operation of UV lamp from causing harm to human body, and more protect the safety of personnel.
◆ The cold-rolled steel plate spray molding process is adopted for the box body, with fine appearance spraying, which can effectively
inhibit the growth of bacteria on the surface of the cabinet body.
◆ Double side perspective window design, better lighting effect, wider field of vision.
◆ The high efficiency filter is designed with negative pressure around the four rings and positive pressure around the operation area,
so as to form a sterile and clean working environment.
◆ Built in HEPA high efficiency filter integrated design, clean air flow covers the whole work area, better wind speed and cleanliness.
Model and technical parameters:
Index / Model | SJ-CJ-1BQ(Horizontal air supply) All stainless steel type |
Cleanliness level | Class 100 @ ≥0.5μm (US Federal 209E) |
Number of colonies | ≤0.5 pcs / dish · hour (φ90mm culture dish) |
Average wind speed | 0.2 ~ 0.5m / s (adjustable) |
Noise | ≤65dB |
Power supply | AC, single item 220V / 50Hz |
Illumination | ≥300LX |
Half-peak vibration | ≤ 3μm(X.Y.Z) |
Maximum power consumption | 350W |
Weight | 75Kg |
Work area size W * D * H | 800×500×600mm |
Device dimensions W * D * H | 900×700×1450mm |
HEPA filter specifications and quantity | 790×600×50×① |
Specification and quantity of fluorescent lamp / ultraviolet lamp | 20w× ①/ 20w ×① |
Applicable number | 1 person operation |
